Platinum-Iridium Alloy Tube
  • Platinum-Iridium Alloy Tube
  • Platinum-Iridium Alloy Tube
  • Platinum-Iridium Alloy Tube

    • Platinum-iridium alloy tube is made from a high-quality blend of platinum (Pt) and iridium (Ir) in a 90/10 ratio (PtIr10). This chemical composition offers excellent biocompatibility, resistance to electrolytic corrosion, and radiopacity, making it an ideal choice for demanding medical environments.

    Widely used in the manufacturing of precision interventional devices, Platinum-iridium alloy tubes are commonly applied in neuroelectrodes, vascular intervention catheters, and other high-reliability implantable or diagnostic medical equipment. The alloy’s mechanical strength, chemical stability, and visibility under imaging systems (such as fluoroscopy) allow for safe and precise navigation within the human body.

    Available Grades: PtIr5, PtIr10, PtIr20, PtIr25, PtIr30
    Outer Diameter: 0.2 - 20 mm
    Wall Thickness: 0.015 - 2 mm
    Length: 10 mm, or customizable

    Contact Us
    Physical Properties
    Grades Melting Point °C Density g/cm Vickers Hardness
    (Soft State)    		 Vickers Hardness
    (Hard State)    		 Tensile Strength
    (MPa)    		 Electric Resistivity
    (uΩ.cm) at 20℃
    Pt-Ir5% 1790 21.49 90 140 274 19.0
    Pt-Ir10% 1800 21.53 130 230 382 24.5
    Pt-Ir20% 1840 21.81 200 200 300 32
    Pt-Ir25% 1840 21.70 200 300 238 33
    Pt-Ir30% 1850 22.15 210 320 242 32.5
    Features
    • Performs reliably at high temperatures above 1500°C without deformation or material degradation
    • Exceptionally resistant to corrosion, even in highly aggressive environments such as aqua regia, chlorine gas, and hydrofluoric acid
    • High strength-to-weight ratio, suitable for use in delicate or miniaturized medical devices under demanding conditions
    Applications
    • Medical devices: Used in neurostimulation electrodes and pacemaker leads for brain and cardiac implants
    • Aerospace: Serves as a flame-resistant nozzle material in rocket engine injectors, withstanding high-temperature combustion of liquid oxygen and kerosene
    • Chemical processing: Applied as liner material in catalytic reactors for hydrofluoric acid production due to its exceptional corrosion resistance
    • Precision instrumentation: Functions as the core electrode in atomic clocks for ultra-stable frequency control
    Packaging
    • Packaging
    • Packaging
    • Packaging
    • Packaging
    • Packaging
    • Packaging
    Why Choose DLX Alloy?
      • Strict Quality Control
        Strict Quality Control
        • Raw material purity is verified through spectrographic analysis, and key production processes are monitored in real time.
        • Finished products undergo 100% inspection, with a pass rate of over 99%.
        • Products comply with applicable standards, including ASTM and GB, and have obtained ISO, TÜV, CE, RoHS, and other certifications.
      • Reliable Delivery
        Reliable Delivery

        Small-batch orders are delivered within 10–30 days, while large-volume orders usually take around 60 days, helping ensure on-time delivery.

      • Customization and Sample Support
        Customization and Sample Support
        • With over 20 years of industry experience, DLX Alloy provides customized alloy solutions, adjusting material specifications and chemical compositions according to customer requirements and offering professional technical support.
        • Standard and custom are available for fast prototyping, with standard samples ready in 7–10 days.
        • Sample testing supports small-batch testing and validation, helping customers verify material performance through actual test data and reduce trial-and-error costs during R&D.
