Copper Alloy

Cast Beryllium Bronze

Cast Beryllium Bronze
Contact Us

Copper Alloy

Cast Beryllium Bronze

Cast beryllium bronze is a copper alloy primarily composed of copper and beryllium, with the beryllium content typically ranging between 0.5% and 2%. It is the highest strength copper alloy, known for its excellent mechanical properties, wear resistance, corrosion resistance, and high-temperature performance.

  • Cast beryllium bronze is one of the highest strength and hardness alloys in the copper alloy family, with significantly improved mechanical properties after heat treatment.
  • It offers outstanding corrosion resistance, particularly in harsh environments such as seawater and salt spray.
  • The alloy retains good mechanical properties even at high temperatures.
  • Cast beryllium bronze has good fluidity and castability, enabling the creation of complex-shaped parts.
  • Its high hardness and strength provide excellent wear resistance.
  • With its high strength and hardness, cast beryllium bronze is ideal for components that endure extreme loads.
Specifications
Cast Beryllium Bronze Plate/Sheet
Thickness 5mm-300mm
Width 200mm-1000mm
Length 1000mm-2000mm
Cast Beryllium Bronze Rod
Diameter 10mm-500mm
Length 500mm-2000mm
Cast Beryllium Bronze Wire
Diameter 1mm-10mm
Chemical Composition
Copper (Cu) Rest
Beryllium (Be) 1.8%-2.1%
Cobalt (Co) 0.2%-0.6% (to enhance age hardening effect)
Other Elements ≤ 0.5% (e.g. nickel and iron)
Physical Properties
Density 8.25-8.4g/cm³
Melting Point 960°C-1025°C
Thermal Conductivity 105-130 W/(m·K) (20°C)
Electrical Conductivity 16%-25% IACS (International Annealed Copper Standard)
Coefficient of Thermal Expansion 17×10⁻⁶/K(20°C-300°C
Mechanical Properties
Tensile Strength Solid solution state 550-800 MPa
After aging treatment 950-1200 MPa
Yield Strength After aging treatment ≥ 600 MPa
Elongation at Break Depending on heat treatment condition 1%-10%
Hardness Solid solution state 200-300 HB
After aging treatment 280-420 HB
